Description
Key features
- Active gyro-stabilization: A two-axis mechanical stabilization system compensates for the vessel’s pitch, heave, and yaw. An integrated Attitude Heading Reference Sensor (AHRS) provides horizontal stabilization to keep the camera pointed at a target in rough seas.
- Pan and tilt: Provides 360° continuous pan and +/-90° tilt, allowing the operator to scan and monitor their surroundings fully.
- High-quality thermal imaging: Powered by the FLIR Boson thermal imaging core, it features a 320×256 VOx microbolometer detector and a 4x continuous e-zoom.
- Low-visibility navigation: Detects obstacles, targets, and other vessels by identifying heat signatures, providing a significant advantage in total darkness, glare, or light fog.
- Rugged design: The camera is built to withstand harsh marine conditions, with a weatherproof, all-weather design and an IPX6 water-ingress rating.
- ClearCruise Augmented Reality (AR): When connected to a compatible Raymarine Axiom multifunction display (MFD), the
M332
can use ClearCruise AR to overlay AIS targets, chart objects, and waypoints onto the live thermal image.
- Connectivity: The camera is designed for seamless integration with other navigation and security systems. It offers multiple video outputs, including IP video streams, HD-SDI, and analog.
- ONVIF compliant: Functionality as a Pan-Tilt-Zoom (PTZ) security camera is supported.
Technical specifications
- Thermal detector: 320×256 VOx Microbolometer
- Field of view: 24° x 18°
- Video refresh rate: 30 Hz or <9 Hz
- Digital zoom: 4x continuous
- Focal length: 9.1mm
- Stabilization: Two-axis mechanical and integrated AHRS
- Operating voltage: 12 to 24V DC
- Ingress protection: IPX6
- Pan/tilt adjustment: 360° continuous pan, +/- 90° tilt
Applications
- Safe navigation: Detects navigation hazards like buoys, floating debris, or other vessels in challenging conditions.
- Man overboard: Helps quickly locate people or pets in the water by detecting their heat signatures.
- Search and rescue: Assists law enforcement and coast guard in locating people in the water or on shore.
- Security: Acts as a PTZ security camera for monitoring and surveillance.
