Semua dalam Satu Paket
VE-PG4 mencakup fungsi RoIP bawaan, gateway SIP, router IP, IP PBX, dan pengontrol terminal komunikasi IP, semuanya dalam satu perangkat (in one box). Dibandingkan dengan sistem serupa yang menggabungkan beberapa perangkat, instalasi dan administrasi dari VE-PG4 yang terintegrasi ini dapat menjadi lebih sederhana, dengan potensi konflik pengaturan yang lebih sedikit.
| Power supply | 12 V DC ±10%, 4 A maximum 100–240 V AC (with the supplied AC adaptor) |
|---|---|
| Operating temperature range | 0 to +40°C, +32 to +104°F |
| Operating humidity | 5–95% (At no condensation) |
| Dimensions (W×H×D) (Projections are not included) |
213 × 36.8 × 270 mm, 8.4 × 1.4 × 10.6 in (Approximate) |
| Weight | 1.8 kg, 4 lb (Main unit, approximate) |
| Regulatory compliance | FCC Part 15 Class B/ ICES003, Part22, Part24, Part27, EN301 489-1, EN301 489-19, EN301 489-52, EN301 908-1, EN301 908-2, EN301 908-13, EN303 413, EN62479, EN62311, EN62368-1 |
| LAN/WAN | RJ-45 type × 1 (Auto MDI/MDI-X) 10BASE-T/100BASE-TX/1000BASE-T *WAN/LAN port selectable. |
|
|---|---|---|
| LAN | RJ-45 type × 1 (Auto MDI/MDI-X) 10BASE-T/100BASE-TX/1000BASE-T |
|
| USB | Host interface | USB 3.0 Standard A receptacles ×3 |
| Console interface | USB 2.0 mini B receptacles ×1 | |
| Network* | 4G bands: | LTE B1, B3, B7, B8, B20 (EUR) LTE B2, B4, B12 (FCC) LTE B1, B3, B5, B7, B8, B28 (AUS) |
| 3G bands: | W-CDMA B1, B8 (EUR) W-CDMA B2, B5 (FCC) W-CDMA B1, B5 (AUS) |
|
| External port | Connectors | 2.54 mm (0.1 in) pitch quick connector (4 terminals ×3) ×4 |
| Audio input | –10 dBs/–40 dBs selectable Input impedance 10 kΩ unbalance |
|
| Audio output | 0 dBs/–20 dBs selectable 600 Ω load unbalance/8 Ω 1 W speaker |
|
| Control input | Low voltage contacts (3.3 V DC/ 1 mA)/ Voltage input (3–16 V) |
|
| Control output | No voltage contacts (30 V/ 100 mA)/ Open collector (3–16 V 10 mA) |
|
* Service availability depends on the country. Network coverage provided by a custom SIM card.
All stated specifications are subject to change without notice or obligation.
